8 Parameter detail setup
134 © Copyright Reserved Autonics Co., Ltd.
8.10.6 Select Print Mode (Backup data recording mode setting)
It is able to print with different record mode from original backup data’s record mode.
Setting range: Graph ↔ Digital
Factory default: Graph
To print with different record mode from original backup data’s record mode, it records with the
set record speed(in case record mode is Graph) or the set record period (in case record mode is
set as Digital) from record mode(Digital or Graph) on current record setup.
For example, in case original backup data is saved as Digital mode (Backup Print Mode:
displays digital). To print with Graph mode (Select Print Mode: set as Graph), Graph mode’s
record speed follows the set record speed of graph mode in current record setup.
How to select record backup file
Move to RECORD BACKUP SETUP parameter setting group.
2nd In Backup Data List, press key and system memory and the saved backup
data in USB are also display. (If backup data is not designated or does not exist, it
displays "File Not Found!!".)
3rd Select the desired file in Basckup Data List and press key and menu is
displayed.
(Marked ‘*’ files displays currently saving file.)
