8 Parameter detail setup
© Copyright Reserved Autonics Co., Ltd. 131
8.10 RECORD BACKUP_ SETUP (Backup data record setting)
Record Backup creates file when power ON regardless of starting/stopping record and saves the
data to inner system memory (An USB memory storage is available (Enable) by the set.)
according the set record mode.
This parameter is useful to print the desired time data with backup data or check data by
computer with DAQMaster (dedicated software).
Therefore, backup data set function is for printing the saved backup data at inner system
memory and an USB memory.
Move to RECORD BACKUP SETUP with , keys, press key to enter
RECORD BACKUP SETUP.
Parameter list
Parameter Setting range Factory default
Record Backup (Backup data record)
Stop ↔ Start
Stop
Backup Data List (Backup data list)
Start Date and Time (Start time for data storage) Date: yyyy/ mm/ dd, Time: hh: mm :ss
End Date and Time (End time for data storage) Date: yyyy/ mm/ dd, Time: hh: mm :ss
Backup Print Mode (Backup data record mode) - Graph
Select Print Mode (Backup data recording mode
setting)
Graph ↔ Digital
Graph
When printing with backup data, the saved data in backup data is accurate but backup data
printout may not be same 100% with the real-data due to the difference between printing
time and backup time. Please use backup data as only for reference.
For printing backup data, KRN100 reads saved backup data in memory from beginning to
end at first and starts printing. If backup data section is long or backup data is saved as low
speed record mode, reading takes a lot of time. Therefore, print only for the desired section.
In graph mode, record speed is changed by Standard speed, Alarm, or Option Speed.
Backup data is printed with Standard speed. Therefore, original printout and backup printout
in graph mode may be different.
