Autonics krn100 series User Manual

8 Parameter detail setup
58 © Copyright Reserved Autonics Co., Ltd.
8.1.8 Range/Scale Point (Decimal point)
In case Input Type(Input specification) is temperature sensor(thermocouple, RTD), set wheter to
display decimal point to measuring value. In case analog(voltage, current), set decimal point
position of Low Scale(Lower limit scalevalue), High Scale(Upper limit scale value).
 Setting range
In case Input Type(Input specification) is temperature sensor(thermocouple, RTD): 0 ↔ 0.0
In case analog(current, voltage): 0 ↔ 0.0 ↔ 0.00 ↔ 0.000 ↔ 0.0000
 Factory default: 0.0
If you want high accuracy display, select ‘0.0(decimal point)’. If you want to stable accuracy
display, select ‘0 (no dicimal point)’.

Autonics krn100 series Specifications

General

Brand	Autonics
Model	krn100 series
Category	Measuring Instruments
Language	English
