1 Overview

1.1 Feature of KRN 100

KRN100 is 100mm hybrid recorder with dot. It combines functions of paper recorder and

paperless recorder by saving function with an USB memory (the world’s first) and by adopting

Trend graph, Bar graph, digital number display function through graphic LCD.

KRN100 enables to print the saved data of system memory as data backup function when run

out of recording paper. KRN100 improves convenience by parameter setting, data transmittion

through RS485 and Ethernet communication (USB device is only for parameter setting), and

backup data logger function.

It also adopts slot type input, output card to connect option card up to 12 channels. It supports

several communication types, of course, and graphic user interface(GUI) with graphic display for

easire and convenient use.

 Combines functions of paper recorder and paperless recorder

 Enables to print the saved data of inner memory when run out of recording paper (Data

logger function)

 Inner data backup with an USB memory

 High legibility and setting convenient by graph LCD

 25ms high sampling, 240mm/h high speed record function

 100mm paper record (Selectable 6 kinds of record color)

 Supports system memory and external memory data backup (storage)

 Supports several input up to 12 channel with slot type input card

 Enables to select several option card with slot type output card

 Supports several communication(RS485, Ethernet) to transfer real time data

 Enables to set parameter with USB Device※1

 Space saving for installation with compact design (Rear length: 168mm)

 Supports total 27 kinds of input sensor

 Enables to order several type input card (weight, voltage, current, frequency, potential

meter, etc)
