2.3 Input specification and measuring range
Input sensor Mark
Measuring range
℃ ℉
K
Thermocouple
K(CA)
TC-K
-200.0 to 1350.0
-328.0 to 2462.0
73.2 to 1623.2
J(IC)
TC-J
-200.0 to 800.0
-328.0 to 1472.0
73.2 to 1073.2
E(CR)
TC-E
-200.0 to 800.0
-328.0 to 1472.0
73.2 to 1073.2
T(CC)
TC-T
-200.0 to 400.0
-328.0 to 752.0
73.2 to 673.2
B(PR)
TC-B
100.0 to 1800.0
212.0 to 3272.0
373.2 to 2073.2
R(PR)
TC-R
0.0 to 1750.0
32.0 to 3182.0
273.2 to 2023.2
S(PR)
TC-S
0.0 to 1750.0
32.0 to 3182.0
273.2 to 2023.2
N(NN)
TC-N
-200.0 to 1300.0
-328.0 to 2372.0
73.2 to 1573.2
C(TT)
※
1
TC-C
0.0 to 2300.0
32.0 to 4172.0
273.2 to 2573.2
G(TT)
※
2
TC-G
0.0 to 2300.0
32.0 to 4172.0
273.2 to 2573.2
L(IC)
TC-L
-200.0 to 900.0
-328.0 to 1652.0
73.2 to 1173.2
L (Russian type)
※
3
TC-L_R
0.0 to 600.0
32.0 to 1112.0
273.2 to 873.2
U(CC)
TC-U
-200.0 to 400.0
-328.0 to 752.0
73.2 to 673.2
Platinel
Ⅱ
TC-P
0.0 to 1350.0
32.0 to 2462.0
273.2 to 1623.2
Resistance
temperature
detector
(RTD)
Cu50Ω
CU50
-200.0 to 200.0
-328.0 to 392.0
73.2 to 473.2
Cu100Ω
CU100
-200.0 to 200.0
-328.0 to 392.0
73.2 to 473.2
JPt100Ω
JPT100
-200.0 to 600.0
-328.0 to 1112.0
73.2 to 873.2
DPt50
Ω
DPT50
-200.0 to 600.0
-328.0 to 1112.0
73.2 to 873.2
DPt100
Ω
DPT100
-200.0 to 850.0
-328.0 to 1562.0
73.2 to 1123.2
Analog
Voltage
-60.00-60.00mV
±60mV
Resolution:10µV
-99999 to 99999
(display range depends on the
decimal point position)
-200.00-200.00mV
±200mV
Resolution:10µV
-2.000-2.000V
±2V
Resolution: 1mV
1.000-5.000V
1-5V
Resolution: 1mV
-5.000-5.000V
±
5V
Resolution: 1mV
-1.00-10.00V -1V-10V
Resolution:
10mV
Current
0.00-20.00mA
0-20mA
Resolution:10µA
4.00-20.00mA
4-20mA
Resolution:10µA
※1. C(TT): Same temperature sensor type as existing W5(TT).
※2. G(TT): Same temperature sensor type as existing W(TT).
※3. Russian type L type temperature sensor is divided from general purpose L type.
When changing input type to voltage (over ±2V) or current, set the jumper pin of KRN-UI2
(universal input card). Its factory default is tempeature sensor input. Refer to the ‘4.2 I/O card’.
