5 NVR System Setup
1. Choose the camera & date.
2. Choose the Report Type: Daily, Weekly, Monthly or Annually.
3. Choose the Cross Type: Cross In or Cross Out.
4. Click Search button, the result will be displayed in either Column Chart or Line Chart.
5. The result can be displayed by Space & Time
5.5 Network
This menu allows you to congure network parameters, such as PPPoE and DHCP. The most common types
are DHCP. Most probably your network type is DHCP, unless the network is manually addressed. If you need
an authentication user name and password to the Internet, then choose PPPoE.
5.5.1 General
If you connect to a router that allows the use of DHCP, please check the DHCP box. The router will
automatically assign all the network parameters for your NVR, unless the network manually addresses
the parameters below:
IP Address: The IP address identies the NVR in the network. It consists of four groups of numbers between
0 to 255, separated by periods. For example, “192.168.001.100”.
Subnet Mask: Subnet mask is a network parameter which denes a range of IP addresses that can
be used in a network. If the IP address is like a street where you live, then the subnet mask is like
a neighborhood. The subnet address also consists of four groups of numbers, separated by periods.
For example, “255.255.000.000”.
Gateway: This address allows the NVR to access the Internet. The format of the Gateway address is the
same as the IP Address. For example, “192.168.001.001”.
DNS1/DNS2: DNS1 is the primary DNS server and DNS2 is a backup DNS server. Just entering the DNS1 serv-
er address should be enough.
5.5.1.1 TCP/IP
