Table 25: Motor Overload Menu Common Installations
Parameter
Default
Description
Motor Overload
0.0 Amps(requiring the user to
set it before running the drive)
Nameplate rating of the motor.
If the motor current exceeds
the Motor Overload value, the
Overload Bucket will begin to
fill using an algorithm that takes
into account how far above
the overload value the actual
current is (usually referred to
as i
2
t algorithm). This algorithm
provides shorter trip delays for
severe overloads and longer trip
delays for slight overloads.
OLoadStartDelay
0.0 Seconds
Seconds after startup during
which overload is ignored.
The default and recommended
OLoadStartDelay is 0 seconds.
OLoad Delay @ 25%
120 Seconds
Time it will take for an empty
overload bucket (0%) to fault
(reach 100%) when the motor
current exceeds the motor
overload by 25%. This setting
does not normally need to be
changed.
Restarts/Allowed
0
Set to non-zero to allow for
automatic restarts after a Motor
Overload fault.
Restart Delay
Global Restart
Delay between the overload fault
and an automatic restart.
Downhole Amps
None
Delay between the overload fault
and an automatic restart.
O-Load Bucket
None
Displays the up to date value of
the Overload Bucket. When the
bucket reaches 100%, the drive
will shut down on overload. This
is a channel and not a parameter.
It need not be changed. It is here
for informational purposes.
Navigate between pages of the menu by pressing the Left Arrow and Right Arrow buttons. The second page
of Overload menu is shown in Figure 87: Overload Menu-Screen 2, page 113.
