Level 2 users will rotate through the following trigger screens:
•
Relevant Triggers – described above
•
Active Triggers – triggers in the Set state
•
Stop Triggers – triggers with an action of Stop->Fault
•
AutoStart Triggers – triggers with restarts allowed
•
Stop-Ready Triggers – triggers with an action of Stop->Ready
•
Start Triggers – triggers with an action of Start Motor
•
Hold Triggers – triggers with an action of Hold in Prestart
•
In Use Triggers – all triggers currently in use by the system
•
All Triggers – all 256 triggers
Keypad Functions:
F1: “Exit” – Exits the settings screen.
F2: “Home” – Closes the current screen and displays the Home screen.
F4: “Next Type” – Displays the next trigger screen in the sequence.
Arrows:
•
Up, Down – Select Event (Login required) to view more info.
•
Right, Left – Page through relevant triggers if there is more than 1 page.
3.9.4
Graph Screens
Pressing F5 “Graph” from most display screens will display a graph screen as shown below
depicting historical data from the first graphable channel on the screen. Pressing F5 again
will show the next channel.
