Copyright 2020 Baker Hughes Company. All rights reserved.
Page 23 of 277
The Drive Mode setting is also available in the “Logged In” settings rotation. To access in the settings
rotation, from the Home Screen repeatedly press the Settings function button. If a window appears asking
you to log in, log in and then continue to press the Settings function button until the Drive Mode parameter is
shown. Set the mode as desired and press the Save function button. Confirm the change.
2.11
Set the Transformer Ratios
See Section 4.4.4 Set DHXFormer Ratio, page 97.
In a Switchboard application, transformer ratios for the CT and PT transformers will need to be set. In the
Switchboard template, use the Quick Start procedure to set the CT and PT transformer ratios.
2.12
Setup a Downhole Tool
See Section 5.2 Setup a Downhole Tool, page 127.
The Wizard will allow the user to select the type of downhole tool, select the units for pressure and
temperature, and set the most commonly used limits.
2.13
Setup Restarts
General Restart InformationSee Section 5.7 Setup Restarts, page 152.
The Wizard will allow the user to select the type of downhole tool, select the units for pressure and
temperature, and set the most commonly used limits.
2.14
Setup Pump Curve
See Section 5.10 Pump Curve Setup, page 160.
2.15
Set the Control Source
The Control Source determines the source of Start commands and set speed commands. Selections are
SCADA + Keypad, SCADA only, and Keypad only.
See Section 5.9 Control Source, page 159.
The Control Source setting is also available in the “Logged In” settings rotation. To access in the settings
rotation, from the Home Screen repeatedly press the Settings function button. If a window appears asking
you to log in, log in and then continue to press the Settings function button until the Control Source
parameter is shown. Set the limit as desired and press the Save function button. Confirm the change.
2.16
Add Apollo I/O Board
See Section 5.1 Add I/O Board, page 126.
2.17
Add a Data Display Screen to the Level 1 Data Rotation
See Section 5.17 Add a Data Display Screen to the Level 1 Data Screen Rotation, page 169.
