Table 9: DSI Switches
Designator
Description
Default
SW2
Operating Mode (16 position
rotary switch)
a
Should be set based on
application.
0 = Vector VII or CTI RTU
6 = Apollo
SW3
Diagnostics/Programming
Leave at default
1 Off
2 Off
3 Off
4 Off
a
The board must be powered off and back on after the Operating Mode has been
changed.
3.2.4 RSTi Expansion I/O Module
Apollo is especially suited for complex Surface Pumping System (SPS) applications. Many SPS
systems include Resistance Temperature Detectors (RTDs) to monitor several locations within
the motor and thrust chamber. To fulfill this requirement, the Apollo system supports the BH
Intelligent Platforms RSTi Expansion I/O modules. Current support is limited to up to 16 RTD
inputs using the 4 and 8 input RTD Modules shown in Table 10: RSTi Expansion I/O Module,
page 34. The system can use any combination of these two modules limited to 16 inputs.
RSTi I/O Components include:
Table 10: RSTi Expansion I/O Module
Description
BH AL Part
Number
BH IP Part Number
Notes
Network Adapters
I/O Network Adapter,
GE,Modbus -485
3000341
Modbus I/O Module
– Required in all
systems
Power Distribution
Modules
