Table 10: RSTi Expansion I/O Module (cont'd.)
Description
BH AL Part
Number
BH IP Part Number
Notes
I/O Remote, GE,
RSTI, Common
Module
3000338
ST-7588
Potential Distribution
Module common for
0 and 24 Vdc
Required for systems
that need to provide
24 Vdc power for
field sensors.
Digital Inputs
I/O Remote, GE,
RSTI, 8CH Dig In
3000337
ST-1218
GE RSTI 8x Digital In
12/24 Vdc positive
logic
RSTI, 4x, Digital
In, (12/24V)
3004919
ST-1214
GE RSTI 4x Digital In
12/24 Vdc positive
logic
Digital Outputs
RSTI, 4x, Digital Out,
(12V, 0.5A)
3004920
ST-2324
GE RSTI 4x Digital
Out (12V, 0.5A)
RSTI, 4x, DIGITAL
OUT, 230 Vac/2A,
24 Vdc/2A
3004923
ST-2744
GE RSTI 4x Digital
Out 230 Vac/2A,
24 Vdc/2A
Analog Inputs
I/O Remote, GE,
RSTI, 4CH RTD
3000336
ST-3704
4 Channel RTD
Module
Requires Breakout
Box (see below)
I/O Remote, GE,
RSTI, 8CH RTD
3000340
ST-3708
8 Channel RTD
Module
Requires Breakout
Box (see below)
I/O
Remote,GE,RSTI,8CH
4-20 Analog In
3000339
,
ST-3218
GE RSTI 8x Analog
In 4~20mA 12bit
RSTI, 4x, Analog
In, Module
3004924
ST-3214
GE RSTI 4x Analog
In 4~20mA 12bit
