Table 7: DIP Switches
Designator
Description
Default
SW2
Board Address
Leave at default unless
multiple I/O boards are being
used. See Section 5.15 Add
a 2nd IO Board, page 165
for more information.
1 Off
2 Off
SW13
Diagnostics/Programming
Leave at default
1 Off
2 Off
3 Off
4 Off
AN1-AN8
Analog Function Select
Used to program the analog
range for analog inputs 1 – 8.
Use the table below to set the
appropriate input ranges.
Digital Input and Output Modules for the I/O board are available as follows:
Table 8: Digital Input and Output Modules
Description
Part Number
Voltage Range
Max Output
Current Input
Impedance
Color
DC Input Module
129130
3.3 to 32 Vdc
1000 Ohms
White
DC Output
Module
129131
3 to 60 Vdc
1.5 Amperes
Red
AC/DC Input
Module
129132
90 to
140 Vac/Vdc
28 K Ohms
Yellow
AC/DC Input
Module
801632
180 to
280 Vac/Vdc
75 K Ohms
Yellow
Switch
1
Switch
2
Range
Off
Off
0-5V
On
Off
0-10V
Off
On
4-20mA
