Table 61: Enable States
Enable State
Description
STOPPED States
Check if you wish the trigger to be enabled when
the drive is stopped. Stopped motor control states
include Initializing, Locked Out, Fault, No Restart,
Hold, and Restart. See Note 1.
Prepare2Start
Check if you wish the trigger to be enabled during
the startup sequence. The motor control state
associated with this is Prep to Start (non ESP
templates) or Wait Backspin (ESP templates).
STARTING State
Check if you wish the trigger to be enabled during
the STARTING state.
RUN MODE 1
Check if you wish the trigger to be enabled when
the drive is in Running.
Note that you can use the different run modes to
have different active triggers… i.e. you can create
multiple underload triggers and have them enabled
in different run states to better protect your system.
RUN MODE 2
Check if you wish the trigger to be enabled when
the drive is in RUN MODE 2.
RUN MODE 3
Check if you wish the trigger to be enabled when
the drive is in RUN MODE 3.
If a trigger has been enabled in all states AND has an enable delay set, then it will be disabled in
the STOPPED States.
10.7 Trigger Screens
Trigger Info Screen
Shown as logged in at Level 2.
Trigger parameters that can be edited from this screen are:
• Trigger Limit
• Trigger Action
• Enable Delay
• Trip Delay
• Restarts Allowed
