Templates are loaded from the Load a New Template selection on the Figure 60: Main
Menu-Screen 2, page 89.
3.4.7 Configuration Wizards
Configuration Wizards are automated procedures that lead the user through the steps necessary
to accomplish various configuration tasks in the Apollo system. Commonly used Configuration
Wizards include:
Table 17: Configuration Wizards
Wizard Name
Wizard Function
Add 1st IO Board
Add support for the Apollo I/O board.
Menu/Other Initial Setup->Page 2
Setup DH Tool
Select a downhole tool to use, pressure and
temperature units, and limits. Menu/Other
Initial Setup->Page 2
Setup Pump Speed PID
Set up the parameters needed to use
the pump speed control PID. Menu/Drive
Mode/PID Mode
Setup Pump Curve
Set the parameters needed to activate the
Pump Curve monitoring capabilities of Apollo.
Menu/Other Initial Setup->Page 2/Pump
Curve Setup/Setup Pump Curve
SPS Setup
Converts the Standard Template for use
in an SPS application. Menu/Other Initial
Setup->Page 2/SPS Setup
Other wizards are available at Menu/Initial Setup->Page 3/Configuration Wizards.
New Configuration Wizards can be added to the system using a USB Flash drive. New
Wizards will be made available via the Support Central Drives and Controls Product
Support website.
3.5 Drive Modes
This section includes an overview of the available drive modes. For additional information, see Section 5.6
Setup Drive Mode, page 139.
3.5.1 Manual Frequency Mode
Control mode in which the drive runs at a programmable speed.
