Mtr Spd PID ‘P” and Mtr Spd PID “I” are the PID Loop proportional and integral constants. Adjust these
to tune the PID.
5.15
Add a 2nd IO Board
The Apollo Well Control System can support a second Apollo I/O board. A second I/O board system may
be needed in SPS Systems with lots of sensors.
Set Switch S2 position 1 to ON, position 2 to OFF on the second Apollo I/O board.
To execute the wizard, from the Home Screen select:
Settings -> Menu -> Other Initial Setup -> Right Arrow -> Right Arrow -> Configuration Wizards -> 2
nd
IO
Board
Follow the on-screen directions.
The 2
nd
IO Board wizard requires no information.
When the wizard is complete, the analog and digital I/O from the added Apollo I/O board will appear in the
Analogs and Digital IO Data Display screens. Analog options are denoted E2 Analog Option 1-8 and
digitals are denoted E2 Dig Opt 1-12.
These new channels can be added to a Data Display screen, if desired.
5.16
Edit a Screen
Apollo Data Display screens can be customized as needed by the application. Figure 132: How to
Customize–Screens 1, page 166 illustrates the process.
1.
Log on as level 2 or level 3.
2.
Navigate to the screen to be customized. In this example, we’ll customize the Home Screen.
3.
Use the Down Arrow button to highlight the screen name.
