Baker Hughes Apollo 3 - Quick Start Parameters for Switchboard Applications

Copyright 2020 Baker Hughes Company. All rights reserved.
Page 19 of 277
Setting ManualStartOnly to false enables automatic starts without warning and may cause
equipment damage, injury to personnel or death.
Table 2: Quick Start Parameters for Switchboard Applications
Parameter Name
Default
Information
Date and Time
None
Set the time zone, date, and time.
Use the Left and Right Arrow
buttons to select a digit to change.
Use the Up and Down Arrow
buttons to change a value. Use
the F1 and F5 function buttons to
navigate between screen fields.
Well Name
Blank
Well Name. Up to 15 characters.
Use the Left and Right Arrow
buttons to move the insert
location. Use the Up and Down
Arrow buttons to change the letter
to the right of the insert position.
Note that Apollo supports USB
Keyboards which simplifies text
entry.
Site Name
Blank
Up to 15 characters. Use the
Left and Right Arrow buttons to
move the insert location. Use
the Up and Down Arrow buttons
to change the letter to the right
of the insert position. Note that
Apollo supports USB Keyboards
which simplifies text entry.
CT Ratio
0.0 A
Input Amps required to yield 5
Amps on the output of the CT.
PT Ratio
0.0 VoltsAC
Input AC Voltage required to yield
120 volts on the output of the PT.
Motor Overload
0.0 Amps
Set to motor nameplate amps.
This setting is used to protect
the motor from heat damage
associated with excess loading.
Note that the default setting of 0.0
Amps requires this parameter be
set prior to running the drive.
