Table 2: Quick Start Parameters for Switchboard Applications (cont'd.)
Parameter Name
Default
Information
Motor Underload
-9,999 Amps
This setting is used to protect
the motor from heat damage
associated with the loss of cooling
fluid moving by the motor caused
by well pump-off. Note that the
default setting of -9999 Amps
requires this parameter be set
prior to running the drive.
Motor Temp High Limit
0.0 °F
Downhole Tool Motor
Temperature High Limit. Drive will
Fault if the Motor Temperature
exceeds the specified limit. Note
that the trigger is Not In Use by
default. The trigger will be set to
“In Use” automatically when the
Limit is changed.
IntakePressLow Limit
0.0 Psi
Downhole Tool Intake Pressure
Low Limit. Drive will Fault if the
Intake Pressure drops below the
specified limit.
D/H VibrationHi Limit
10.00 G’s
Downhole Tool Vibration High
Limit. Drive will Fault if the
Vibration exceeds the specified
limit.
Global Restart
60 Minutes
The default auto-restart time, in
minutes, for all system faults.
Note that the restart time for
any trigger (fault detection
mechanism) can be customized
from the Trigger Info screen.
PwrFail SysStop
0
Restart delay after a power loss
Restarts/Allowed
when running. The default value
is the global restart time. When
the value is changed, the user
can specify whether the new
value applies only to the PwrFail
SysStop trigger or if the global
restart time should be changed.
