Level 2 and Level 3 users can customize the data on this screen. See Section 5.16
Edit a Screen, page 165.
•
Default data shown in image is for an ESP system. SPS and Switchboard applications
have different default data.
3.8.2
Data Display Screens
Level 1 users access Data Display screens by pressing the Data function button from the Home
Screen. Repeatedly pressing the Data function button allows the user to view all of the available
data display screens.
By default, Data Display Screens include the Downhole screen, Digital and Analog I/O screens,
and the Amp Chart screen.
A list of all the Data Display screens appears when a Level 2 or Level 3 user presses the Data
function button on the Home Screen. The user can then highlight the desired screen using the up
and down arrows and navigate to the highlighted screen by pressing the Select function button.
Additional screens are also added based on the configuration. For example, if a level 2 user
configures the pump curve parameters, the pump curve screen will be added to the Data
Display screens.
3.8.3
Downhole Screen
Function
The Downhole screen displays the data from the downhole sensor (usually Baker Hughes’ Osiris downhole sensor).
This screen
will not be available if there is no downhole tool configured in the system.
