Table 33: Sensors (cont'd.)
Sensor
Communications
Notes
GRC Scout 3000
RS-485
Com3 (RS-485) recommended if
no I/O board present.
Com2 (RS-485) OK if not used for
SCADA. Requires P/N 800638.
Centinel
RS-485
Com3 (RS-485) recommended if
no I/O board present.
Com2 (RS-485) OK if not used
for SCADA.
Requires P/N 800638.
• Low Intake Pressure Limit: A low intake pressure limit may be set. Also note that the trigger action and
restart parameters may also be adjusted as necessary.
• Motor Temperature High Limit: A high motor temperature limit may be set. Also note that the restart
parameters may also be adjusted.
• Intake Temperature High Limit: A high motor temperature limit may be set. Also note that the restart
parameters may also be adjusted.
When the wizard is complete, the Apollo system will reboot.
Data for the downhole tool appears on the Downhole data screen. The navigation path is Home Screen
-> Data -> Downhole Sensor Screen.
To configure limits on the downhole parameters, navigate to Home Screen -> Settings -> Menu -> Downhole
Limits.
5.3 Install RSTi I/O Module
Execute the Install IO Module wizard to enable Apollo to use the RSTi I/O Module. To execute the wizard,
from the Home Screen select.
Settings -> Menu -> Other Initial Setup -> Next Page (Right Arrow) -> Install IO Module.
At this time, only the RSTi 8 RTD setup wizard is available. Contact product support if more than 8 RTD
channels are required.
Follow the on-screen directions.
Information needed by the Install IO Module wizard:
• Units (Degrees F or Degrees C) for the temperature channels.
When the wizard is complete, the RSTi I/O, RSTi temperature channels will appear on a new Data display
screen named Motor Temp.
