Table 35: Drive Mode Menu #2 (cont'd.)
Trigger to control the Ramp 1 Speed. Edit this
trigger to be active when the ramp should take
effect. By default , the trigger is “Not In Use”, “Active
when Enabled”, and “Enabled only in Run Mode 1”.
To enable the ramp feature, select the Ramp Enable
Trigger and from the Trigger Info screen, press
F3 “On/Off” to activate the trigger. This is all that
is required to enable ramping during every speed
change. More selective enabling of the ramp can
be done by re-configuring the Ramp Enable trigger.
Frequency Ramps are available only in Manual
Frequency Mode and only after the drive has
reached the Start Frequency and transitioned to
one of the Run Modes. A frequency ramp allows for
a slow fixed rate ramp when the drive frequency
setpoint changes. This ramp is only invoked when
the Ramp 2 Enable trigger is set. Note that the
ramp time is in minutes per Hertz.
Trigger to control the Ramp 2 Speed. Edit this
trigger to be active when the ramp should take
effect. By default , the trigger is “Not In Use”, “Active
when Enabled”, and “Enabled only in Run Mode 2”.
See Ramp 1 Enable for details on how to enable
the ramp feature.
5.6.1
Manual Frequency Mode
Control mode in which the drive runs at a programmable speed.
