Trigger Actions (Basic)
“Basic” Trigger Actions are appropriate for at least 90% of the triggers that will need to be field configured.
See Trigger Actions (full list) below for all trigger actions.
Table 60: Trigger Actions (basic)
Color Scheme
(background)
The trigger has no effect on the
motor control state machine and
is not logged. The Logic Only
trigger can be used as an input to
other (derived) triggers.
The trigger has no effect on the
motor control state machine but is
logged in the Event Log.
The trigger will cause the motor
to stop. On drives, the motor
will stop according to the normal
acceleration/deceleration times
or coast as configured. A fault
will be declared. If no restarts
remain on the trigger, the system
will Lock Out.
Text colors are only as listed when the Apollo Color Scheme is set to “Color on Black”.
10.6
Enable States
Enable States can only be selected on the Trigger Edit screen (Advanced Access required).
