Table 10: RSTi Expansion I/O Module (cont'd.)
Description
GE AL Part
Number
GE IP Part Number
Notes
Analog Outputs
RSTI, 2x, Analog
Out, 0-20mA
3004918
ST-4112
GE RSTI 2x Analog
Out 0-20mA
Other Components
Module,interface
Screw/Ribbon Conn
3003172
Breakout Box – One
required for each 8
or 4 channel RTD
module.
Each Breakout Box
requires one of the 3
cables listed below.
Ribbon,Cable Flat
20PIN FEM 18INCH
RSTi
3003169
Connects Field Wiring
Block to RTD Module
Ribbon,Cable Flat
20PIN FEM 10INCH
RSTi
3003170
Connects Field Wiring
Block to RTD Module
Ribbon,Cable Flat
20PIN FEM 6INCH
RSTi
3003171
Connects Field Wiring
Block to RTD Module
