Table 63: Trigger Actions (full list) (cont'd.)
Action (User Level)
Color Scheme (background)
Description
STOP->FAULT
(Basic)
Red
The trigger will cause the motor
to stop. On drives, the motor
will stop according to the normal
acceleration/deceleration times.
A fault will be declared. If no
restarts remain on the trigger, the
system will Lock Out.
STOP->Ready
(Standard)
Red
The trigger causes the motor
control to stop the motor without
issuing a fault or a lockout. In
the hold state, a trigger with the
START Motor action can cause
the motor to start.
STOP->Timer Block
(Advanced)
Red
The trigger causes the motor
control to stop the motor AND
will restart only on that trigger’s
restart timer. The system will not
allow manual starts to override
the timer.
HOLD in Prestart
(Standard)
Blue
The trigger will cause the motor
control to wait in the Prestart
state. The motor control will
remain in the Prestart state until
the trigger is cleared (and then
the motor will be started) or until
another trigger causes a transition
to the fault or lockout state. The
HOLD in Prestart trigger is usually
used as a permissive for running
the system.
START Motor
(Standard)
Green
The trigger will cause the motor
to start IF the motor control is in
the HOLD state.
Go to Run Mode 1
(Advanced)
Dark Green
The trigger will cause the motor
control to transition to Run Mode
1.
Go to Run Mode 2
(Advanced)
Dark Green
The trigger will cause the motor
control to transition to Run Mode
2.
