C8000 Battery Testing System User Manual
3 Cadex BatteryLab 193
Field
Default State
Description of the Program Parameter
about the program.
Comment 2
Blank
Comment Field that can be used to store information
about the program.
Custom waveform
Blank
Attaches a custom waveform to the program. The
program will run the indicated waveform, for the steps
that indicate Custom waveform.
Dchg Playback waveform
Blank
Attaches a Playback waveform to the program. This
waveform is only used if a Discharge Playback action
step is with in a program.
Analog Input/Output
Unchecked
Enables any of the Analog input or output port of the
C8000. Check mark the Analog ports to enable
The Analog output ports have a 0~5 volt range and the
output value is controlled in the Action Parameter Tab.
Analog Input Range
0~5v
Configures the input voltage range for the associated
Analog Port.
Options available:
0~5 volts
0~10 volts
0~15 volts
Digital Input/Output
Off
Configures the associated Digital Port as digital input or
a digital output.
Options available:
Off
Input
Output
3.10.4.2 Remove a Step from a Program
To delete a step, select the step and click Delete. The step is
removed from the list.
3.10.4.3 Copy a Step in a Program
To create a duplicate step, select the step to copy and click Copy.
The new step appears in the list.
3.10.4.4 Save the Custom Program
Click OK to save the program.
