C8000 Battery Testing System User Manual
28 2 Battery Tester
constant voltage
 Nickel-based = constant current (DC
charge) with optional Reverse Load Charge
method
 Discharge Methods
 Constant current
 Constant power
Data Acquisition
 System Sample Rate
500 microseconds
 Termination Data (last 500
samples) Capture Rate
2~200 milliseconds
 Capture/Display Rate (non-
termination)
1~60 seconds
Certification
 Safety
CSA, UL, CE
 Environmental
RoHS, WEEE
2.4.2 Auxillary Port Absolute Maximum Ratings
When using the Auxiliary Input/Output Connector, the voltage
settings for the pins must not exceed the absolute maximum
ratings – otherwise the C8000 may become damaged. The absolute
maximum ratings for the Auxiliary Input/Output Connector are
as follows:
Voltage Setting
Maximum Rating
Voltage at Digital I/O 1-4:
-0.1 to +6V
Voltage at SMBC, SMBD or
SMBDIO:
-0.1 to +5.5V
Voltage at Analog Output 1-2:
-0.1 to +6V
Voltage at T+ or P+:
-0.1 to +5V
Voltage at Differential Analog
Input 1-4 (either input, relative
to ground):
-50 to +50V
Voltage at Differential Analog
±50V
