2.4 C8000 Specifications
2.4.1 C8000 System Techincal Specifications
 Channels
4 Independent Channels each including:
 1 Battery Port + 1 I/O Port
Physical
 Dimensions
480mm x 380mm x 140mm (18.9” x 15.0” x 5.5”)
 Weight
15.5 kg (34 lb)
 Mounting Options
Desktop or 19” (483mm) 3U Rack-mount
 Display
5.7” (145mm) QVGA 320x240 graphics with
backlight
 Battery Ports (front panel)
4 Ports each including:
 Battery Positive (+)
 Battery Negative (-)
 Sense Positive (+)
 Sense Negative (-)
 Thermistor Input
 Thermistor Ground
 Auxillary Ports (I/O) (front panel)
4 x DB25 Type each including:
 4 Differential Analog Inputs: 0-5V, 0-10V, or
0-15V
 4 Digital Inputs: 0-5V
 2 General Purpose Analog Outputs: 0-5V
 SMBus Enabled: 5 Possible Termination
Signals
 Active Data Ports (back panel)
 Ethernet 10/100MB for connection to PC
 Designated Serial Port for External Load
 Designated Serial Port for Environmental
Chamber
Environment
 Operating Temperature
5ºC-35ºC (40ºF-95ºF)
 Storage Temperature
-20ºC-70ºC (-4ºF-160ºF)
