C8000 Battery Testing System User Manual
Battery Tester 25
Auxiliary data cables (for I/O ports) Wiring Chart
Pin #
Function
Wire Color
1
Digital I/O 1
White
2
Digital I/O 2
Yellow
3
Digital I/O 3
Orange
4
Digital I/O 4
Pink
5
Analog Out 1
Gray
6
Analog Out 2
Brown
7
Ground
Black
8
+5VDC
Red
9
SMBC
Purple/white
10
SMB D I/O
Brown/white
11
SMB DO
Black/white
12
Reserved
Yellow/black
13
Reserved
Pink/black
14
Ground
Green
15
Temperature (T+)
Blue
16
Pressure (P+)
Purple
17
Differential Analog Input 1 Positive (+)
Red/white
18
Differential Analog Input 1 Negative (-)
Red/black
19
Differential Analog Input 2 Positive (+)
Orange/white
20
Differential Analog Input 2 Negative (-)
Orange/black
21
Differential Analog Input 3 Positive (+)
Green/white
22
Differential Analog Input 3 Negative (-)
Green/black
23
Differential Analog Input 4 Positive (+)
Blue/white
24
Differential Analog Input 4 Negative (-)
Gray/black
25
Ground
Light green
Shell
Earth
Drain
