2.2.2 Connect the C8000 Adapter Unit to the C8000.
1. Align the notch on the battery connector cable plug with the
notch on the battery connector and push in the cable.
2. Push the battery connector plug in while turning the ring on
the battery connector clockwise until the lock is engaged.
See 2.3.2 Connect the Power Port Cable to the C8000 for
instructions on how to connect the Power Port Cable.
3. Push the DB25 female connector in to corresponding
Auxiliary connector of the C8000 channel and tighten the
connector hand screws.
To remove the battery connector cable from the C8000, turn the
ring on the connector plug counter-clockwise and then pull the
cable plug out of the connector.
