C8000 Battery Testing System User Manual
96 3 Cadex BatteryLab
6. In the File Storage Duration field, enter a value 0-999, where
0=off. This is the number of days the C8000 will keep all
test results before automatically deleting all files that are
older than the specified number of days. Note that no
warning is issued before deletion.
7. In the Screen Saver field, enter a value 0-60, where 0=off.
This is the number of minutes before a Cadex screen saver
is enabled. (If pixel retention occurs, the active screen saver
and the pixel retention will be corrected.)
8. In the SnapLock Auto Import field, select Yes or No. This
option automatically imports all c-codes stored on a
SnapLock/RigidArm Adapter, when inserted. (Note: C-
codes will remain until the adapter is removed.) The
naming scheme used during auto-import is as follows: The
assigned name will be “C7xyy” where x=Channel # (1-4),
yy=c-code # (location) in the adapter (01-10). For example,
a c-code imported from Channel 3, with a C-Code in
memory location #1 would be: C7301.
9. In the RDD Free Space Alert field, enter 0-1000 (kilobytes).
The C8000 will issue a warning when the available free
space reaches or surpasses the specified value.
10. Adjust the LCD contrast for the C8000 by moving the
slider to the left or right. Note: Moving the cursor to the
right will darken the screen, while moving the cursor to
the left will lighten the screen.
11. Click OK.
3.1.16 Alert Window
The Alert window may appear when BatteryLab is first
executed and will display and warning or error information.
For each warning/error condition, the Alert window displays
the unit number and IP address of the C8000 that has issued
the warning; the date and time the warning occurred; the test
identification number (ID) of the service issuing the warning,
and text with an explanation of the warning/error. The Alert
window may also display information on how to correct the
warning/error condition.
