C8000 Battery Testing System User Manual
Battery Tester 13
Current: 3A
2.1.3.3 SnapLock
TM
Universal Battery Adapter (4-wire versions only)
SnapLock
TM
gives a precise connection to the battery allowing for
easy hook up. The adapter contains C-Codes that can be used to
configure the C8000 and other Cadex platforms to the correct
setting. Specialty adapters available on request. Requires C8000
Adapter Unit.
Specifications:
Voltage: 18V
Current: 3A
2.1.3.4 Load Capture Unit (LCU)
LCU captures and stores load signatures (in BatteryLab) of any
device up to 100A in real-time. Capture a power tool load
signature (or any other electronic device) by drilling through a
steel beam. Then apply a repeatable load signature to any battery
to determine; performance characteristics, battery life, time of use,
etc. Other applications for the LCU include spinning up a hard
drive on a laptop or accelerating an electric motor.
Specifications:
Buss-bar Current:
o 0-10A (2% of Full Scale, Ripple: 20mA)
o 0-100A (2% of Full Scale, Ripple: 50mA)
External Current Clamp:
o 0-400A (1% of Full Scale, Ripple: 500mA)
Voltage Input Terminals:
o 500mV~48V (2% of Scale, Ripple: 20mV)
Capture Frequency:
o DC to 250Hz
Thermal Couple:
o Supports K-type –
±2°C plus Thermal Couple accuracy
2.1.3.5 C8000 Rack Mounting Bracket Set
For 19” 3U mounting type rack. (PN# 92-470-0054)
