Battery Tester 43
A
Fully Charged
Finished
B
Terminate Charge Alarm
Finished
C
Overcharged Alarm
Finished
D
Fully Discharged
Finished
E
Terminate Discharge Alarm
Finished
F
Over-Temperature Alarm
Two retries
The following are definitions for available actions on the
status/alarm bits:
A
Finished
The C8000 will end the
current step as a success.
B
Fail
The C8000 will end the
current step as a failure.
C
Ignore
The C8000 will ignore this
flag and continue the current
step.
D
# Retries
# indicates a value between 1
and 10. This option is
available for Over-
Temperature Alarm bit only.
The setting will indicate to the
unit the number of SM-Bus
samples with the over-
temperature alarm bit set
before the C8000 will
terminate the step as a fail.
(Note: SM-Bus is sampled at
15-second intervals.)
2.7.1.7 Select a Program to Run
Select a program with which to test the connected battery.
(Note: All programs require battery parameters to be
established by selecting either a Battery ID or a C-Code.
Pressing C-Code “Edit” button, for either Battery ID or C-code
can modify the battery parameters).
