C8000 Battery Testing System User Manual
98 3 Cadex BatteryLab
3.2 Configure BatteryLab
3.2.1 Results Panel
BatteryLab can be customized to display specific fields in the
Results window. The Available Fields column lists the fields that
can be displayed in the Results window. The Display Fields
column displays the fields that will be displayed in the Results
window.
The following table describes the variables that are available for
display by the Results window.
Variable
Description
Voltage
Voltage reading from the C8000
Current
Current reading from the C8000
Step
Current step within a program
Step Duration
The duration of the current step
Step Description
A user-defined description of the current step
Status
The current status of the C8000 channel or program
Pgm Name
The executing program’s name
Result
The test result of the current program
Test ID
Test Identification (ID) number that has been
assigned automatically to the service/test
Duration
The total duration of the entire program
Cap %
Capacity reading from the C8000
Chrg Cnt
Number of Charge steps that have been applied
during the program
Dchg Cnt
Number of Discharge steps that have been applied
during the program
Battery ID
The Battery Identification (ID) that has been
assigned.
AnalogOut1
Voltage level of the first Analog output
AnalogOut2
Voltage level of the second Analog output
DigitalOut1
Status of Digital 1 when configured as an output
DigitalOut2
Status of Digital 2 when configured as an output
