C8000 Battery Testing System User Manual
3 Cadex BatteryLab 99
Status of Digital 3 when configured as an output
Status of Digital 4 when configured as an output
Status of Digital 1 when configured as an input
Status of Digital 2 when configured as an input
Status of Digital 3 when configured as an input
Status of Digital 4 when configured as an input
Voltage level of Analog Input 1
Voltage level of Analog Input 2
Voltage level of Analog Input 3
Voltage level of Analog Input 4
Temperature reading from C8000
Impedance milli-ohm reading from C8000
Indicates the basic condition of the Thermal
Chamber. (Hold and Running)
The temperature reading from supported thermal
chambers
1. From the Tools menu, select BatteryLab Configuration.
The BatteryLab Configuration window appears.
