2-162
CHAPTER 2 NEW FUNCTIONS
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
3) Remove the two screws [3], and discon-
nect the connector [4]; then, detach the
fixing heat discharge fan [5].
[3]
[4]
[5]
F02-706-07
e. Removing the Delivery Cooling Fan
1) Remove the left cover.
2) Remove the filter [1].
[1]
F02-706-08
