Chery A1 2009 - Page 267

• Check voltage between ECM terminals 16 (APP sensor 4), ECM terminal 40 (APP sensor 1) and ground under
the following conditions:
APP SENSOR REFERENCE DATA
TERMINAL NO. ITEM CONDITION
DATA (DC
VOLTAGE)
16
Accelerator Pedal
Position Sensor
Ignition switch: ON
Engine stopped
Accelerator pedal:
Fully released
0.72 - 0.74 V
Engine stopped
Accelerator pedal:
Fully depressed
3.95 V
40
Accelerator Pedal
Position Sensor
Engine stopped
Accelerator pedal:
Fully released
0.36 - 0.37 V
Engine stopped
Accelerator pedal:
Fully depressed
1.97 V
Is the check result normal?
Yes
>> Go to step 11.
No
>>
Replace the Accelerator Pedal Assembly (See Accelerator Pedal Position Sensor Removal & Installa-
tion in Section 03 Electronic Engine Controls).
Perform accelerator pedal position learning.
Perform throttle valve position learning.
7.
CHECK THE TPS SIGNAL CIRCUIT FOR AN OPEN OR SHORT
• Turn ignition switch off.
• Disconnect the ECM electrical connector.
• Check continuity between the electronic throttle control actuator terminal 5 and ECM terminal 38, and electronic
throttle control actuator terminal 6 and ECM terminal 54.
• Continuity should exist.
• Check harness for short to power or short to ground.
Is the check result normal?
Yes
>> Go to the next step.
No
>> Repair or replace the open circuit, short to power or short to ground in harness or connectors.
8.
CHECK THE TPS GROUND CIRCUIT FOR AN OPEN OR SHORT
• Check continuity between the electronic throttle control actuator terminal 2 and ECM terminal 78.
• Continuity should exist.
• Check harness for a short to power and short to ground.
Is the check result normal?
Yes
>> Go to the next step.
No
>> Repair or replace the open circuit or short to power or short to ground in harness or connectors.
