6. Remove the front exhaust pipe retaining bolts (1).
(Tighten: Front exhaust pipe bolt to 50 ± 5 N·m)
7. Remove the exhaust pipe (See Exhaust Pipe
Removal & Installation in Section 07 Exhaust).
8. Remove the vehicle speed sensor retaining bolt (1)
and set it aside.
(Tighten: Vehicle speed sensor bolts to 10 ± 1
N·m)
9. On each side of the steering gear, remove the nut
(1) attaching the outer tie rod end to the steering
knuckle.
(Tighten: Outer tie rod end nut to 40 ± 5 N·m)
10. Using special tool CH-10002, separate the outer tie
rod ends from both steering knuckles.
ON-VEHICLE SERVICE
PZSM100029
PZSM100011
LTSM110034
LTSM110027
10
10–19
Chery Automobile Co., Ltd.
