32. Disconnect the clutch cable (1) from the clutch
housing and position it aside.
33. Lower the vehicle and install engine lift chain hangers.
34. Remove the two front engine mount bolts (1) and
the four front engine mount bracket bolts (2).
(Tighten: Engine front mount bolt to 80 ± 5 N·m)
35. Remove the rear engine mount bolt (1) and the
three rear engine mount bracket bolts (2).
(Tighten: Engine rear mount bolt to 60 ± 5 N·m)
ON-VEHICLE SERVICE
PZSM080034
PZSM020032
PZSM020011
02–38
Chery Automobile Co., Ltd.
