4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-47
16:9 16:9 Auto None No conversion. Normal
picture.
16:9 16:9 16:9 L/B None Conversion is not possible.
Normal picture.
16:9 16:9 4:3 CCO None Conversion is not possible.
Normal picture.
16:9 16:9 4:3 P/B None Conversion is not possible.
Normal picture.
16:9 16:9 14:9 None Conversion is not possible.
Normal picture.
16:9 16:9 16:9 SCALE None Conversion is not possible.
Normal picture.
16:9 4:3 None None Picture appears tall and thin.
16:9 4:3 16:9 L/B 16:9 L/B Vertically down-samples the
picture and applies black
bars at the top & bottom of
the screen.
16:9 4:3 4:3 CCO 4:3 CCO Horizontally up-samples the
centre portion of the picture
to fill the 720.
16:9 4:3 4:3 P/B None Conversion is not possible.
Picture appears tall and thin.
16:9 4:3 14:9 14:9 Compromises some up-
sampling. Some black bars
and some cropping are
visible.
16:9 4:3 16:9 SCALE None Conversion is not possible.
Picture appears tall and thin.
Stream TV A/R Conversion Act Conv Description Image
