4-26 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setup Menu: Admin
Structure
To view the Admin menu from the Main menu, press the SELECT key.
For instructions on how to select and store settings, see About the Front Panel,
page 4-2.
The Admin menu has the following structure:
Admin
Reboot
i
s
Factory Reset Clear FWD Tables
i
s
KB Lock KB Lock Timeout
Disabled 1200
i
s
DL Mode Limit Version
FPGA Once 1.01.01
i
s
DL Status Type Bank
Running UnforcedPMT Application
i
s
CDT# Recv Reject Command
8417 8417 0 Restart
i
s
Date Format Time Format GMT Off
MM_DD_YYYY 24Hr SuspendZero +12:00
i
s
Lock Level Password
0 ****
i
s
Old Pwd New Pwd Confirm Pwd
**** **** ****
i
s
LCD Contrast
30
i
s

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
