5-26 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setting up Custom Tuning Parameters
To Set up the Custom Tuning parameters
Proceed as follows to set up the Custom Tuning parameters:
1. From the user interface of the D9854, click the Setup tab and then click the
Custom icon from the sub-page.
2. Set the Frequency Tuning mode, which determines whether the receiver is to be
tuned to the received signal using the NIT or User Cfg (user configurations).
3. The Service List mode determines which tables to use to obtain tuning and
channel lists.
Select Rigorous if all the default settings must be present in the received signal.
Select Degraded if only the table parameters present in the received signal will
be used to install the receiver. The default is Rigorous.
4. The remaining fields allow you to set up your custom and fixed PID properties.
The following table shows some possible configurations for the allowed service
lists and the different frequency tuning settings.
Allowed Service Lists Custom Fixed PID
Bouquet Association Table (BAT)
(not supported)
NN
Network Information Table (NIT) N N
Service Description Table (SDT) N N
Program Association Table (PAT) Y N
Frequency Tuning mode User Cfg User Cfg
