Control and Management Interfaces
Ethernet
The Management interface for the D9854 receiver is the 10/100/1000 BaseT
Ethernet interface. It is used for upgrading the software application.
Front Panel Control
The front panel keypad and LCD are used to control and monitor the operating
parameters of the D9854 receiver.
The following diagram shows the front panel with its different sections.
Numeric Keypad
LCD Panel
Navigation/Selection
Alarm LED
Signal LED
CI Slots
