A-12 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Audio Outputs
Analog Audio Outputs
Digital Audio Outputs
Conditional Access
Item Specification
Number of Channels 2 stereo pairs/4 mono channels, 5.1 channel
downmix Audio decompression: MPEG or
Dolby Digital (AC-3). HE-AAC single
stereo pair or Dolby Digital Plus single
stereo pair available as future software
download.
Frequency Response ±0.5 dB, 20 Hz to 20 kHz (ref., 100 KΩ)
Total Harmonic Distortion < 0.3% at 1 kHz (ref. 100 KΩ)
Dynamic Range 85 dB (CCIR/Arm weighting)
Crosstalk 80 dB at 1 kHz (typical)
Item Specification
Number of Channels 2 (one stereo channel each)
Format AES-3id
Connector BNC
Item Specification
PowerVu CA DES or DVB
DVB Scrambling BISS Mode 1, Biss Mode E
DVB-CI Interface: 2 CI slots - EN 50221
CA Method: Multicrypt, Simulcrypt
CAS: Irdeto, Viaccess, Nagravision, Conax
CAS: MediaGuard, Cryptoworks available
in an anticipated future software release
Note: Viasat (uses NDS/VideoGuard) only
authorizes decoders equipped with an ASI
output to receive/decrypt Viasat-
encrypted programs.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
