Cisco D9854 User Manual

4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 5-67
Viewing the Alarm/Warning Status
To View the Alarm and Warning Status Information
Proceed as follows to view the Alarm/Warning Status page:
From the user interface of the D9854, click the System tab and then the Alarm/
Warning Status icon from the sub-page.
The Alarm and Warning Status page displays all the active event messages for the
D9854 system.
The following table shows the alarm/warning status table information:
Status Description
Category Type of message (alarm or warning).
Number Active Displays the number of alarms and warnings that
have an active status.
Type Shows whether it is an alarm or a warning message.
Name Name of the alarm or warning. For more
information on alarm messages, refer to Messages,
page 6-3.
Text Content of the message.
Set Since Date and time of the alarm or warning.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
