Setup Menu: TS Input
Structure
To view the TS (Transport Stream) Input menu from the Main menu, press the
RIGHT arrow key once and then the SELECT key to reach the Setup menu. Then
press the RIGHT arrow key once and the SELECT key to view the TS Input menu.
For instructions on how to select and store settings, see About the Front Panel,
page 4-2.
The TS Input menu has the following structure:
Main:Setup:TS Input
Input Tune Mode Re-acquire
i
s
Satellite OrbPos E/W Pol
Yamal 102 90.0 NA H
i
s
Tune Mode Status
LO1(GHz) LO2(GHz) Crossover(GHz)
10.75 10.75 12.00
i
s
Frequency Tuning
Preset
i
Service List Mode BAT NIT SDT PAT
Rigorous Yes Yes Yes Yes
i
Frequency Tuning
Preset
i
s
Service List Mode BAT NIT SDT PAT
Rigorous Yes Yes Yes Yes
i
s
RFx Active Tune Mode CA Ctl Select
Act FixPID Open UserCfg
i
s
Freq(GHz) SymRate FEC L-Band RFLock
15.000000 28.3465 Auto 1640.0 No Loc
i
s
InputIQ NetID
NonInv 00016
i
s
LNB Power 22kHz
H-NIT Auto
i
s
Custom Setup
Main:Setup:TS Input:Input
ASI RF1 RF2 RF3 RF4
i
s
ASI Input
RFx Input
ASI Active Tune Mode CA Ctl Select
Act FixPID Open RF Map
i
s
Modulation Rolloff
DVB-S2 .35
i
s
Main:Setup:TS Input
Custom Status
i
s
Orbital Position Validation Date
2008/04/01 12:43:56
i
Validate Orbital Position: No
Status: None
i
s
To Next Page
