4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-15
Status Menu: General
GENERAL STATUS
Input
Description: Indicates the active input port receiving the signal.
Status
Description: Indicates the current signal lock status for the selected RF input.
Parameters: Signal Lock - See table.
Rate (Mbps)
Description: Indicates the bit rate of the received input signal.
Parameters: in Mbps.
Level (dBm)
Description: Indicates the signal level of the received signal.
Parameters: in dBm.
PE
Description: Indicates the Program Entry number.
Parameters: PE1 to PE16.
Mode
Description: Indicates the type of CA used for the received signal, e.g., SA or
BISS.
Auth
Description: Indicates whether the receiver is authorized to receive the signal.
Parameters: Yes, No.
Status Description
Locked Indicates the receiver is locked to a carrier
with no valid content.
Lock+Sig Indicates the receiver is locked to a carrier
with valid content.
No Lock Indicates the receiver is not locked to a
carrier.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
