A-14 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Section D - Control and Management Interfaces
Ethernet Management Interface
Ethernet Data Interface
RS-232 Data Interface
Alarm Interface
Item Specification
Number of connectors 1
Type of connector Eight-pin RJ-45
Ethernet type 10/100/1000 Base-T
Required setup IP address, default gateway and subnet
mask
Item Specification
Number of connectors 2
Type of connector Eight-pin RJ-45
Ethernet type 10/100/1000 Base-T
Required setup IP address, default gateway and subnet
mask
Item Specification
Connector type 9-pin sub-D female
Data rates RS-232 asynchronous data at selectable
rates up to 38.4 kb/s: 300, 1200, 2400, 4800,
9600, 19,200, 38,400 b/s
Item Specification
Number of outputs 3, each having one set of contacts closed
and one set open during normal operation.
Alarms are signalled by reversing the
polarity of the two contact sets.
Type of connector Terminal block
Max. voltage ≤ 30 V AC, ≤ 30 V DC
Max. current ≤ 1 A
