4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-57
Setup Menu: Common Interface (CI)
Structure
To view the CI menus from the Main menu, press the RIGHT arrow key once and
then the SELECT key to reach the Setup menu. Then press the RIGHT arrow key
four times and the SELECT key to view the CI menu.
The Common Interface (CI) slots are located under the door on the front panel.
They allow use of a CAM (Conditional Access Module) Smart Card to decrypt
purchased programming.
Note: You must be authorized to view the programming available via the Smart
Card from your service provider.
Note: CAMs must be purchased from Cisco. For a list of the supported CAMs, see
Common Interface Modules, page 3-18.
For instructions on how to select and store settings, see About the Front Panel,
page 4-2.
The CI menu has the following structure:
i
s
Query AutoReset ListMgmt
Disabled Disabled AddDel
i
s
i
s
PE Decrypt CI Slot
12 ON TOP
Idx PE Mode PID StreamType Inst
03 10 PID 2120 unkn 00 00
TS_ON_ID TS_ID ON_ID
NotUsed 2048 1024
i
s
CAM status overview
Top slot Bottom slot
i
s
System Name
Irdeto Aston Pro 2.15
i
s
Application Manufacture ID
0x600
i
s
Manufacture Code
0x600
i
s
Supported CA System IDs
Irdeto (0x600)
i
s
Serial Number
1600-102755
i
s
Hardware Version
1.0000
i
s
Application version
2.1508B
i
s
CI
COMP Only
Status
Ready
i
s
System Name
Irdeto Aston Pro 2.15
i
s
Application Manufacture ID
0x600
i
s
Manufacture Code
0x600
i
s
Supported CA System IDs
Irdeto (0x600)
i
s
Serial Number
1600-102755
i
s
Hardware Version
1.0000
i
s
Application version
2.1508B
i
s
Status
Ready
i
s
Product Name
xxx
i
s
Company Name
xxx
i
s
To Next Page
Loading...
