4021470 Rev D Model D9854 Advanced Program Receiver Installation and Operation Guide 3-1
Chapter 3
Installation
Overview
Introduction
This chapter describes how to install the D9854 Advanced Program Receiver. Before
installing the D9854 Advanced Program Receiver, read all safety precautions and
guidelines thoroughly.
Qualified Personnel
Only appropriately qualified and trained personnel should attempt to install,
operate or maintain the D9854 receiver.
In This Chapter
This chapter contains the following topics.
WARNING:
Allow only qualified personnel to install this product. Otherwise, personal
injury or equipment damage may occur.
Topic See Page
Section A - Rack Installation 3-3
General 3-3
Section B - Rear Connector Panel 3-6
Overview 3-6
Section C - Connecting the Input/Output Signals 3-8
Connecting the RF Inputs 3-8
Connecting the Audio Outputs 3-9
Connecting the Audio Outputs 3-9
Connecting the Ethernet Management Interface 3-10
Connecting the IP TS Output 3-11
Connecting the ASI Output 3-12
Connecting an External Alarm System 3-13
Connecting the RS-232 Data Interface 3-14
Connecting the Cue Tone/Cue Trigger Interface 3-15
To Next Page
