A-16 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Section E - Power and General Specifications
General
Power
AC Power Connector
Power
To operate the receiver, you must connect it to an AC power source.
Item Specification
LCD 2 lines of 40 characters, backlit LCD.
Keypad Arrow keys, 0 to 9, SELECT, MENU, INFO, ADV, MAP,
APPLY and NAV keys.
LEDs Green LED for Signal status. Red LED for Alarm indication.
Item Specification
Type of connector IEC 320 style C14 appliance receptable
AC input 100 to 240 V AC, 50/60 Hz
Power 37 W max.
Current 0.34 A @ 240 V AC typical, 0.5 A @ 120 V AC typical
Power Quality ANSI/IEEE Std C62.41.1-2002
WARNING:
Make sure that at least one end of the power cable(s) remains easily accessible
for unplugging, if you need to switch off the unit. For example: Ensure that the
socket outlet is installed near the product.
WARNING:
To avoid electrical shock, connect the three-prong plug on this product to an
earth-grounded three-pin socket outlet only.
