4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-13
Main Menu
Operation of the D9854 receiver begins at the Main menu. From the startup screen,
press the MENU key to view the Main menu.
Menu Selection
Select the desired function by moving the cursor left or right by pressing the LEFT
or RIGHT arrow key. Once a selection is made by pressing the SELECT key, the
LCD presents the second menu level for the selected function. Succeeding levels for
each function include all the hierarchical levels for the function in the front panel
LCD. For example, the TS Input level is shown as Main: Setup: TS Input, with each
succeeding level separated by a colon (:), as shown in the example below. The front
panel menus are described on the following pages.
Main Menu 1/2
Status Setup About Versions
i
s
Main Menu 2/2
Diagnostics
i
s
Main Menu 1/2
Status Setup About Versions
i
s
Main:Status
General Services TS Input TS Output
i
s
Main:Setup 1/2
Admin TS Input IP Services CI
i
s
Main:Setup 2/2
Outputs CA Alarm/Warning NoiseCutoff
i
s
Main:Setup:TS Input
Input Tune Mode
i
s
2
nd
level
3
rd
level
1
st
level
To Next Page
